TPC96 POWERCLAM
TPC96 Powerclam Grapples Are Engineered for Superior
Durabilty. The T-MAR TPC96 is
designed for cut-to length loading and chucking / shoveling. The Heavy Duty construction can match the
power of modern medium sized carriers handling multiple stems.
What Sets the TPC120 Series Apart
-
Extremely Strong Mid-Section and Leg Assemblies
with QT100 Construction
-
Hardened Pins and Aluminum Bronze Bushings
Throughout
-
End and Center Leg Pin Lugs Prevent Lug
Tear-Offs
-
Extended 110mm Thick Wall High Pressure
Cylinders, Load Holding Counterbalance Valves
-
High Pressure Easy Access Swivel
-
Good Service Access for Protected Hoses and
Components
-
Protected, Dual Direct Drive Rotate Motors for
Durability and Slew Power
Options
-
Valve on Machine and Valve In Head Options
Available
-
Lugging to Suit Carrier
-
Top or Bottom Tilt/Heel Cylinder Configuration
Best Suited For
Cut To Length with Medium Sized Carriers
Specifications: TBD
Machine Weight: 75,000 lbs. +
-
Attachment Weight: 5950 lbs.
-
Cylinder Diameter: 5" / 125 mm
-
Closing Force: 22,600 ft-lb
Rotate Flow: 25 GPM
Rotate Torque: 25,000 ft-lb
Rotate Pressure: 3,700 PSI
Open/Close Pressure: 4,000 PSI
Open/Close Flow: 60–95 GPM
he T-MAR Powerclam Grapple combines brute strength with unmatched precision. Whether you’re clearing land, loading wood, or processing debris, this grapple is purpose-built to keep you productive in the toughest forestry environments. Looking for something bigger? Check out the TPC120 POWERCLAM!
